Atom

Atom

  • 2.1 Cu.ft Front Load Washer
  • Inverter Direct Drive
  • Soft Mount Installation
  • Compact Design
  • Over-suds Reduction
  • Power Wash Program
Technical Specifications

LG Atom Washer

Heater Type Non-Heater Type
Model Number WD-B12337D9 F12A9TDP3S
Cylinder
Drum volume ℓ 58 58
Diameter in.(mm) – –
Depth in.(mm) – –
Capacity kg(lb) 6 (13.23) 6 (13.23)
Dimensions
Product (WxHxD) in.(mm) 23.62 (600) x 21.65 (550) x 33.46 (850) 23.62 (600) x 21.65 (550) x 33.46 (850)
with door opening in.(mm)
Carton (WxHxD) in.(mm) 25.98 (660) x 25.79 (655) x 34.84 (885) 25.98 (660) x 25.79 (655) x 34.84 (885)
Weight (Product/ Carton) kg(lb) 62 (136.68) / 66 (145.50) 62 (136.68) / 66 (145.50)
Speed
Wash RPM 45 45
Extract (High Speed) RPM 1,200 1,200
Rating
Voltage / Frenquency V 220V,50Hz 230V,50Hz
Water Usage
Water Consumption ℓ 66 66
Noise & Cycle Time
Noise Level (Sound Power) dB Lower than 62 Lower than 62
Program duration in minutes(Default) min 52 (Whites) 106 (BOIL)
System & Control
Inverter Direct Drive Motor Available Available
Intelligent Electronics Controls Available Available
3 Compartment Dispenser Available Available
Heating System W 2000 2000
Forced Drain System W Available Available
Pricing Program Card OPL
Wash Programs Temperature Program Temperature Program
WHITES 52 mins –
COLORS 52 mins –
PERM PRESS 50 mins –
DELICATE 48 mins –
SPIN ONLY 11 mins –
ADD SUPPER WASHER 5 mins –
Boil – 106 min
Disinfection – 91 min
Hot – 76 min
Warm – 55 min
Cold – 36 min
Covenience Features
End of Cycle Beeper Available Available
Door Lock Display Available Available
Auto Balancing Available Available
Auto Suds Removal Available Available
Forced Drain System Available Available
Remaining Time Display Available Available
Status Indicator Available Available
4 Adjustable Leveling Legs Available Available
Password Setting Available Available
External Finish Available Available
Drum NeveRust™ Stainless Steel Drum NeveRust™ Stainless Steel Drum
Top Plate Available Available
Transparent Glass Window Door Available Available
Colors Stone Silver Stone Silver
Cabinet Painted Steel Painted Steel
Control Panel Plastic panel Plastic panel
Window Display DUAL LED DISPLAY DUAL LED DISPLAY
LG GIANT-C PLUS WASHER

LG GIANT-C PLUS WASHER

  • 2.1 Cu.ft Front Load Washer
  • Inverter Direct Drive
  • Soft Mount Installation
  • Compact Design
  • Over-suds Reduction
  • Power Wash Program
Technical Specifications

LG GIANT-C PLUS WASHER

Model Number F1069FD* (Non-Heater Type) F1069FDS* (Heater Type)
Cylinder
Drum volume cu. ft.(ℓ) 4.2 (102.7) 4.2 (102.7)
Diameter in.(mm) 22.05 (560) 22.05 (560)
Depth in.(mm) 16.51 (419.3) 16.51 (419.3)
Capacity kg(1:10)/lb 10.2 / 22 10.2 / 22
Dimensions
Product (WxHxD) in.(mm) 27 (686) x 38.70 (983) x 29.75 (756) 27 (686) x 38.70 (983) x 29.75 (756)
with door opening in.(mm) 50.81 (1,291) 50.81 (1,291)
Carton (WxHxD) in.(mm) 29.72 (755) x 44.37 (1,127) x 31.30 (795) 29.72 (755) x 44.37 (1,127) x 31.30 (795)
Weight (Product/ Carton) lb(kg) 191 (87) / 205 (93) 191 (87) / 205 (93)
Speed
Wash RPM 45 45
Extract (High Speed) RPM 1,150 1,150
G-force G 413 413
Energy
Electric Power Consumpsion V/Hz/A 120/50/5 220~240/50/5 220/60/5 220~240/50/15~17.5
Water Usage
Water Consumption ℓ 42.4 86
Noise & Cycle Time
Noise Level (Sound Power) dB Lower than 62 Lower than 62
Program duration in minutes(Default) min 37 60 (60℃ program)
System & Control
Inverter Direct Drive Motor • •
Intelligent Electronics Controls • •
Heating System W – 3,200
3 Compartment Dispenser • •
Forced Drain System • •
Pricing Program Special Vended Price Special Vended Price
Wash Programs
Whites (Hot) 90℃ (90min)
Colors (Warm) 75℃ (75 min)
Delicates (Cold) 60℃ (60min)
Permanent Press (Warm) 40℃ (48min)
Super Wash Added (Option) Cold (36min)
Rinse and Spin(OPL only, 23min)
Covenience Features
End of Cycle Beeper • •
Door Lock Display • •
Self Diagnosis • •
Auto Balancing • •
Auto Suds Removal • •
Forced Drain System • •
Remaining Time Display • •
Status Indicator • •
4 Adjustable Leveling Legs • •
LoDecibel Quiet Operation • •
Coin Box Open Sensing • •
External Finish
Drum NeveRust™ Stainless Steel Drum NeveRust™ Stainless Steel Drum
Top Plate Porcelain (Single) / Painted Steel (Stack) Porcelain (Single) / Painted Steel (Stack)
Transparent Glass Window Door • •
Colors White White
Cabinet Painted Steel Painted Steel
Control Panel Steel Steel
Window Display Silk Screen Silk Screen
Window Aluminum Aluminum
Circuit Protection
PCB fuse – Main Control Board amps 8 (220~240V/50Hz) 8 (220~240V/50Hz)
PCB fuse – Filter Assembly amps 15 15
LG GIANT-C DRYER

LG GIANT-C DRYER

  • 7.1 Cu.ft Elec/Gas Dryer
  • 4 wheels supporting drum
  • Powder Painted Coating
  • Reversible Dryer Door
  • Steel Control Panel
Technical Specifications

LG GIANT-C DRYER

Model Number RN1329A*** (Gas type) RN1329A*** (Electric Type)
Cylinder
Drum volume cu. ft.(ℓ) 7.1(201) 7.1(201)
Diameter in.(mm) 26.1 (663) 26.1 (663)
Depth in.(mm) 22.46 (570.6) 22.46 (570.6)
Capacity kg(1:20)/lb 10 / 22 10 / 22
Dimensions
Product (WxHxD) in.(mm) 27 (686) x 38.70 (983 )x 29.96 (761) 27 (686) x 38.70 (983) x 29.96 (761)
with door opening in.(mm) 49.8 (1,264) 49.8 (1,264)
Carton (WxHxD) in.(mm) 29.92 (760) x 46.06 (1,170) x 31.30 (795) 29.92 (760) x 46.06 (1,170) x 31.30 (795)
Weight (Product/ Carton) lb(kg) 130 (59) / 143 (65) 130 (59) / 143 (65)
Operation
Electrical Requirements V/Hz/amps 120/60/5 220~240/50/2.35 220/60/2.35 120(240)/60/26 220~240/50/22.5 240/50/19.5
Heating type Gas Electric
Type of Drying Ventilation Ventilation
Motor KW 0.42 (120V/ 60Hz) 0.32 (220~240V/ 50Hz) 0.4 (220V/ 60Hz) 0.42 (120V/ 60Hz) 0.32 (220~240V/ 50Hz) 0.4 (220V/ 60Hz)
Gas Ratings KW 5.8 (EU)1) –
Heating Element W – 54002)
Program duration in minutes(Default) min 45 45
Connections
Air outlet diameter in.(mm) 4 (100) 4 (100)
Exhaust airflow diameter in.(mm) 4 (100) 4 (100)
System & Control
Pricing Program Special Vended Price Special Vended Price
Intelligent Electronic Controls • •
Dry Programs
White & Colors • •
Perm. Press • •
Delicates • •
No Heat • •
Covenience Feature
End of Cycle Beeper • •
Heater Type – Multi-level control
Gas Valve Type on / off –
Reversible Door • •
Remaining Time Display • •
Self Diagnosis • •
Status Indicator • •
4 Adjustable Leveling Legs • •
Coin Box Open Sensing • •
External Finish
Top Plate Porcelain (Single) / Painted Steel (Stack) Porcelain (Single) / Painted Steel (Stack)
Transparent Glass Window Door • •
Colors White White
Cabinet Painted Steel Painted Steel
Control Panel Steel Steel
Window Display Silk Screen Silk Screen
Window Aluminum Aluminum
TITAN C WASHER

TITAN C WASHER

  • 5.2 Cu.ft Front Load Washer
  • Inverter Direct Drive
  • Soft Mount Installation
  • Top Mounted Dispenser
  • Atomizing System
  • Auto Dosing Ready
  • Gravity Drain
  • 4 Damper System
  • Powder Painted Coating
  • Emergency Button(OPL)
Technical Specifications

TITAN C WASHER

Payment Type (CARD/COIN) OPL Type
Cylinder
Drum volume cu. ft.(ℓ) 5.16 (147) 5.16 (147)
Capacity kg(1:10)/lb 15 / 30 15 / 30
Dimensions
Product (WxHxD) (mm) 737 x 1036 x 814 737 x 1036 x 814
with door opening (mm) 5.16 (147) 5.16 (147)
Weight (Product/ Carton) lb(kg) 5.16 (147) 5.16 (147)
Speed
Wash RPM 46 46
Extract (High Speed) RPM 980 980
System & Control
Inverter Direct Drive Motor • •
Intelligent Electronics Controls • •
Heating System W 1000 w (Only for Tub clean) 1000 w (Only for Tub clean)
3 Compartment Dispenser • •
Drain System Gravity Drain Gravity Drain
Pricing Program Special Vended Price Special Vended Price
Emergency Stop Button – •
Auto dosing Interface • •
Wash Programs
Hot • •
Warm • •
Cold • •
Delicates • •
Super Wash Added (Option) • –
Custom PGM – •
Covenience Features
End of Cycle Beeper • •
Door Lock Display • •
Self Diagnosis • •
Auto Balancing • •
Auto Suds Removal • •
Remaining Time Display • •
Status Indicator • •
4 Adjustable Leveling Legs • •
4 Damper 4 friction damper( ASK 80N) 4 friction damper( ASK 80N)
LoDecibel Quiet Operation • •
Coin Box Open Sensing • •
Auto Dosing ready • •
Atomizing ( Twin sptay) • •
Gravity drain • •
External Finish
Drum NeveRust™ Stainless Steel Drum NeveRust™ Stainless Steel Drum
Top Plate Porcelain (Single) Porcelain (Single)
Transparent Glass Window Door • •
Colors Stainless Silver Stainless Silver
Cabinet Cover Painted Steel Painted Steel
Control Panel Painted Steel Painted Steel
Frame,Panel Painted Steel Painted Steel
Frame,Panel lower Painted Steel Painted Steel
Window Display 88:88 LED Display 88:88 LED Display
Window Display sheet Aluminum Aluminum
Circuit Protection
PCB fuse – Main Control Board amps 8(220~240V) / 12(120V) 8(220~240V) / 12(120V)
PCB fuse – Filter Assembly amps 15 15
TITAN C DRYER

TITAN C DRYER

  • 9.0 Cu.ft Gas Dryer Linear
  • Gas & Blower Control (Energy Saving)
  • 6 wheels supporting drum
  • Powder Painted Coating
  • Reversible Dryer Door
  • Steel Control Panel
Technical Specifications

TITAN C DRYER

Model Number Titan C gas dryer
Cylinder
Drum volume cu. ft.(ℓ) 9.0(255)
Diameter in.(mm) 28.19(716)
Depth in.(mm) 24.17(614)
Capacity kg(1:20)/lb 13.6 / 30
Dimensions
Product (WxHxD) in.(mm) 29 (686) x 43.9 (1114) x 40.8 (1036)
with door opening in.(mm) 61.57 (1,564)
Carton (WxHxD) in.(mm) 31.4 (797) x 48.1 (1,222) x 44.3 (1,126)
Weight (Product/ Carton) lb(kg) 220.4(100) / 240(108.8)
Operation
Electrical Requirements V/Hz/amps 120/60/8
Heating type gas
Type of Drying ventilation
Motor KW 0.5 (120V/ 60Hz)
Gas Ratings KW / BTU 16.1 (EU)1) / 55,000
Heating Element W –
Program duration in minutes(Default) min 10/0.25$
Connections
Air outlet diameter in.(mm) 6 (154)
Exhaust airflow diameter in.(mm) 6 (154)
System & Control
Pricing Program Special Vended Price
Intelligent Electronic Controls •
Dry Programs
White & Colors •
Perm. Press •
Delicates •
No Heat •
Covenience Features
End of Cycle Beeper •
Heater Type –
Gas Valve Type on / off & Linear
Reversible Door •
Remaining Time Display •
Self Diagnosis •
Status Indicator •
4 Adjustable Leveling Legs •
Coin Box Open Sensing •
External Finish
Top Plate Porcelain (Single) / Painted Steel (Stack)
Transparent Glass Window Door •
Colors Stainless steel
Cabinet Painted Steel
Control Panel Steel
Window Display Silk Screen
Window Aluminum
GIANT C STACK

GIANT C STACK

  • 3.63 Cu.ft Frond Load Washer
  • Inverter Direct Drive
  • Soft Mount Installation
  • Top Mounted Dispenser
  • Atomizing System
  • Pump Drain 3 Damper System.
  • 7.1 Cu.ft Elec/Gas Dryer
  • 4 wheels supporting drum
  • Powder Painted Coating
  • Reversible Dryer Door
  • Steel Control Panel.
Technical Specifications

GIANT C STACK
